| Size - 10" |
| Impedance: 4 |
| RMS Watts: 350 |
| Music Program: 700 |
| Resonance 69.8 Hz |
| Sensitivity: 94.6 dB |
| Voice Coil Diameter: 2.5" |
| Sold As - Single |
| Driver Composition |
| Voice Coil Wire: CCAW |
| Coil: KSV |
| Magnet: Ferrite |
| Basket: Stamped Steel |
| Cone: paper |
| Cone Edge: cloth |
| T/S Parameters |
| Resonant Frequency (fs) 69.8 |
| DC Resistance (RE) 3.2 |
| Coil Inductance (LE) 0.43mH |
| Mechanical Q Qms) 7.57 |
| Electromagnetic Q (QES): 0.47 |
| Total Q (QTS) 0.44 |
| Compliance Equivalent volume (VAS) 26.1 |
| Mechanical Compliance of Suspension (CMS) 0.16 |
| BL Product (BL) 10 N/A |
| Diaphragm Mass Inc. Airload (Mms) 33.5gr |
| Mounting Information
|
| Overall Diameter: 257mm |
| Cutout diameter: 233.84mm |
| Mounting Depth: 107mm |
