| Size - 8" |
| Impedance: 8Ω
|
| Nominal Power - 75 Watts |
| Dynamic Power - 350 Watts |
| Resonance 96.2 Hz |
| Sensitivity: 96.5 dB |
| Voice Coil Diameter: 1.5" |
| Sold As - Single |
| Driver Composition |
| Voice Coil Wire: CCAW |
| |
| Magnet: Ferrite |
| Basket: Stamped Steel |
| Cone: paper |
| Cone Edge: cloth |
| T/S Parameters |
| Resonant Frequency (fs) 96.2 |
| DC Resistance (RE) 5.8 |
| Coil Inductance (LE) 0.00mH |
| Mechanical Q (Qms) 6.74 |
| Electromagnetic Q (QES): 1.84 |
| Total Q (QTS) 1.45 |
| Compliance Equivalent volume (VAS) 13.9 |
| Mechanical Compliance of Suspension (CMS) 0.20 |
| BL Product (BL) 5.1 N/A |
| Diaphragm Mass Inc. Airload (Mms) 13.6gr |
| Mounting Information
|
| Overall Diameter: 209mm |
| Cutout diameter: 181.5mm |
| Mounting Depth: 68.3mm |
