| PWM Power Supply |
| Maximum RCA Input Level: 14V RMS |
| Maximum RCA Output Level: up to 13V |
| Frequency Response: 10Hz - 100KHz ; +/- 1dB |
| Total Harmonic Distortion: 0.003% |
| Signal To Noise Ratio: 130 dB |
| Balanced Input Noise Rejection: > 60 db |
| Input Impedance: 10K Ohms |
| Output Impedance: 150 Ohms |
| Power Supply: High Headroom PWM |
| Power Draw: 150 mA |
| Recommended Fuse Rating: 1 Amp |
| DIMENSIONS: |
| L: 7.20 in./ 182.88 mm |
| W: 5.20 in./ 132.08 mm |
| H: 1.50 in./ 38.1 mm |
