| Nominal Impedance : 4+4Ω |
| Speaker Sensitivity : 84dB |
| Nominal Music Power : 750 Watts |
| Maximum Music Power : 3000 Watts |
|
| Dimensions |
| Overall Diameter: 10.67"/ 271 mm |
| Mounting Depth: 5.91"/ 150 mm |
| Cutout Diameter: 8.92"/ 226.67 mm |
|
| TS PARAMETERS
|
| Resonant Frequency (fs): 32.7 Hz |
| D.C. Voice Coil Resistance (Re): 4Ω |
| Mechanical Quality Factor (Qms): 4.795 |
| Electrical Quality Factor (Qes): 0.612 |
| Total Quality Factor (Qts): 0.543 |
| Equivalent Air Volume to Cms (Vas): 20.02 L |
| Cms: 0.118 mm/N |
| Mass of Diaphragm/Coil (Mms): 200 g |
| Force Factor (BL): 10.732 N/A |
| Sound Pressure Level (SPL): 84 dB |
