| Nominal Impedance : 4+4Ω |
| Speaker Sensitivity : 86dB |
| Nominal Music Power : 750 Watts |
| Maximum Music Power : 3000 Watts |
|
| Dimensions |
| Overall Diameter: 12.82"/ 325.78 mm |
| Mounting Depth: 11.22"/ 285.08 mm |
| Cutout Diameter: 6.50"/ 165 mm |
|
| TS PARAMETERS
|
| Resonant Frequency (fs): 30 Hz |
| D.C. Voice Coil Resistance (Re): 4Ω |
| Mechanical Quality Factor (Qms): 5.48 |
| Electrical Quality Factor (Qes): 0.654 |
| Total Quality Factor (Qts): 0.58 |
| Equivalent Air Volume to Cms (Vas): 48 L |
| Cms: 0.122 mm/N |
| Mass of Diaphragm/Coil (Mms): 225 g |
| Force Factor (BL): 10.558 N/A |
| Sound Pressure Level (SPL): 86 dB |
