| 1 x 1500 Watt @ 1Ω Mono
|
| 1 x 750 Watt @ 2Ω Mono
|
| 1 x 375 Watt @ 4Ω Mono
|
| THD at Rated Power <0.5% |
| Bandwidth (-3 dB) - 18Hz- 250Hz |
| Damping Factor (1k Hz @ 4Ω) - 126 |
| Signal to Noise Ratio >90dB |
| Input Sensitivity: 200Mv - 6V |
| Minimum Load Impedance - 1Ω mono |
| Phase Shift Selector - 0-180* |
| Mono Low Pass Filter Slope - 12dB |
| Low Pass filter range - 30Hz-250Hz |
| Sub - Sonic Filter slope - 12dB |
| Sub - Sonic Filter Range - 10Hz-50Hz |
| Selectable Bass Boost @45Hz - 0-12dB |
| 275mm |
| W - 237.38mm |
| H - 52mm |
