| 1 x 1000 Watt @ 1Ω Mono
|
| 1 x 500 Watt @ 2Ω Mono
|
| 1 x 250 Watts @ 4Ω Mono
|
| THD at Rated Power <0.5% |
| Bandwidth (-3 dB) - 18Hz- 250Hz |
| Damping Factor (1k Hz @ 4Ω) - 126 |
| Signal to Noise Ratio >90dB |
| Input Sensitivity: 6V - 0.2V |
| Minimum Load Impedance - 2Ω mono |
| Phase Shift Selector - 0-180* |
| Mono Low Pass Filter Slope - 12dB |
| Low Pass filter range - 40Hz-300Hz |
| Sub - Sonic Filter slope - 12dB |
| Sub - Sonic Filter Range - 10Hz-40Hz |
| Selectable Bass Boost @45Hz - 0-12dB |
| 200mm |
| W - 237.38mm |
| H - 52mm |
