| 4 x 75 Watts @ 4Ω |
| 4 x 150 Watts @ 2Ω |
| 1 x 600 Watts @ 2Ω (5the Ch) |
| Ch 1-2 High Pass Crossover: 40Hz - 300Hz |
| Ch 3-4 High Pass Crossover: 40Hz - 300Hz |
| Ch 5 Low Pass Crossover: 40Hz - 300Hz |
| Subsonic Filter: 0 - 25 Hz |
| Crossover Slope @ 12 dB |
| Bass Boost @ 45Hz : 0-12dB |
| Input Sensitivity: 250Mv - 6V |
| Signal to Noise ratio : >92dB |
| Frequency Response:10Hz-22KHz |
| |
| |
| DIMENSIONS:
|
| L: 9.75" / 248mm |
| W: 5.50" / 140mm |
| H: 2" / 51mm |
