| 6 x 125 Watts @ 4 ohms |
| 6 x 185 Watts @ 2 ohms |
| 3 x 325 Watts @ 4ohm (Bridged) |
| Ch 1/2 High Pass / Low PAss Filter Variable: 50 Hz - 4 Khz |
| Ch 3/4 High Pass / Low Pass Filter Variable: 50 Hz - 4 KHz |
| Ch 5/6 High Pass / Low Pass Filter Variable: 50 Hz - 4 KHz |
| Working Voltage: 9.3 -16 Volts |
| Frequency Response: 20Hz - 20KHz |
| Signal to Noise Ratio @ Rated Power 91dB |
| Low Level Input Range : 300MV - 6V
|
|
| DIMENSIONS |
| L- 13.8"/ 352 mm |
| W- 5.2"/131 mm |
| H- 2.05"/52 mm |
