| 4 x 115 Watts @ 4 ohms + 1 x 400Watts @ 4 ohms |
| 4 x 150 Watts @ 4 ohms + 1 x 585Watts @ 2 ohms |
| Ch 1/2 High Pass / Low Pass Filter Variable: 50 Hz - 4 Khz |
| Ch 3/4 High Pass / Low Pass Filter Variable: 50 Hz - 4 Khz |
| Ch 5 Low Pass Filter Variable: 50 Hz - 200 hz |
| Working Voltage: 9.3 -16 Volts |
| Frequency Response: 20Hz - 20KHz |
| Signal to Noise Ratio @ Rated Power 97dB |
| Low Level Input Range : 300MV - 6V
|
|
| DIMENSIONS |
| L- 13.8"/ 352 mm |
| W- 5.2"/131 mm |
| H- 2.05"/52 mm |
